cheap energy saving preminum refrigerated compressed air dryer used in air compressor
Product Description
cheap energy saving preminum refrigerated Compressed Air Dryer used in Air Compressor Product Description SLAD Series Air-cooled Refrigerated Air Dryer
Technical Parameters: Working Pressure: 0.6-1.6MPa Flow Capacity: 0.5-80Nm3/min
Pressure Dew Point: 2-10℃
Air cooled Type Air Inlet Temperature:Standard Type≤45℃ High Temperature Type ≤80℃ Ambient Temperature:≤38℃ Plate fin type heat exchanger Air cooled type refrigerated compressed air dryer specification:
Air-Cooled Type Refrigerated Air Dryer(Built In Pre Cooler)
Working condition and technical data
0.5-12Nm³/min,100-600Nm³/min
0.5-12Nm³/min,100-600Nm³/min Optimization scheme of high temperature air inlet equipment
Maximum inlet air temperature: 80℃
Ambient temperature: 5 ℃ - 50 ℃
Pressure range: 0.6-1.6mpa (0.5-12nm3 / min)
0.6-1.0mpa (100nm3 / min and above)
Pressure dew point: 2-10 ℃
Cooling mode: air cooling 1) Ensure the normal operation of the equipment at the ambient temperature of 50 ℃
2) 0.5-80 cubic meter adopts environment-friendly refrigerant; the plate / plate fin heat exchanger with the functions of recuperator, evaporator and gas-liquid separator has good heat transfer effect, compact and beautiful structure, modular refrigeration components, convenient disassembly and repair, and strong replaceability.
3) R22 refrigerant and shell and tube heat exchanger are used for more than 80 cubic meters; the three-stage separation mode of "direct collision separation + low-speed centrifugal separation + stainless steel wire mesh demisting separation" is adopted for the gas-liquid separator to separate 99.9% liquid water from the cooled compressed air to prevent the secondary evaporation of water and ensure the low dew point quality of finished gas;
4) Danfoss of Denmark, Fusheng of Taiwan, Panasonic of Japan, Bitzer of Germany, Copeland of Germany, high of Shanghai and other companies are used as refrigeration compressors, which have stable operation, low noise, high cop, reliable performance and long service life;
5) Advanced Danfoss, Emerson and Sporlan are used as refrigeration control elements;
6) Real time display of operation parameters Packaging & Shipping We have three packaging methods:
1. Carton + wooden bottom support
2. Ordinary wooden box + bottom bracket
3. Fumigated wooden box packaging
If other requirements, other packaging can be in accordance with customer requirements
Company Information Shanli purify is a CE and ISO:9001 leading air dryer manufacturer with more than 24 years experience in China. Our products include: >Refrigerated air dryers >Desiccant air dryers >Water Chiller >Pre-cooler >Air filters
Advantages Refrigerant Compressed Air Dryer Advantage:
1.Rapid and Accurate Service-solving Capabilities
2.Sales Marketing: Accurate, timely solution to pre-sale communication problems (pre-sales)
3.Logistics Department Production Department Quality Department: Timely production and delivery in accordance with the quality system standards (sale)
4.After-sales service department: a strong after-sales service network, professional service engineers covering
domestic and global, (after sales)
5.Clients
Major customers: Fu Sheng, Atlas, Ingersoll Rand, Boge, CompAir, SCR and other international
famous brand.
Related Products
Contact US your questions are important to us - we guarantee a response within 1 business day Enter your inquiry details such as product name,color,size,Quantity,cell number ,etc Send Inquiry Now > > > Emily Chen
Shanli Purify Equipment Corporation
24Years Experiend In Air Dryer Industry
Direct Line:0086-571-57897051
Wechat/ Whatsapp/Zalo: +86 18037466416
www.shanlidryer.com/www.hzsljh.com Contact us if you need more details on Air Dryer. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Types Of Air Dryer、10 Hp Rotary Screw Air Compressor With Dryer. If these products fail to match your need, please contact us and we would like to provide relevant information.
Technical Parameters: Working Pressure: 0.6-1.6MPa Flow Capacity: 0.5-80Nm3/minPressure Dew Point: 2-10℃
Air cooled Type Air Inlet Temperature:Standard Type≤45℃ High Temperature Type ≤80℃ Ambient Temperature:≤38℃ Plate fin type heat exchanger Air cooled type refrigerated compressed air dryer specification:
| Model | Capacity | Refrigerant | Diameter | ||
| Capacity | (m3/h) | (cfm) | |||
| SLAD-0.5NF | 0.65 | 39 | 23 | R134a | G1" |
| SLAD-1NF | 1.2 | 72 | 42 | R134a | |
| SLAD-2NF | 2.5 | 150 | 88 | R134a | |
| SLAD-3NF | 3.6 | 216 | 127 | R410A | |
| SLAD-4.5NF | 5 | 300 | 176 | R410A | G1 1/2" |
| SLAD-6NF | 6.8 | 408 | 240 | R410A | |
| SLAD-8NF | 8.5 | 510 | 300 | R410A | G2" |
| SLAD-10NF | 10.9 | 654 | 384 | R410A | |
| SLAD-12NF | 12.8 | 768 | 451 | R410A | |
Working condition and technical data
0.5-12Nm³/min,100-600Nm³/min
0.5-12Nm³/min,100-600Nm³/min Optimization scheme of high temperature air inlet equipment
Maximum inlet air temperature: 80℃
Ambient temperature: 5 ℃ - 50 ℃
Pressure range: 0.6-1.6mpa (0.5-12nm3 / min)
0.6-1.0mpa (100nm3 / min and above)
Pressure dew point: 2-10 ℃
Cooling mode: air cooling 1) Ensure the normal operation of the equipment at the ambient temperature of 50 ℃
2) 0.5-80 cubic meter adopts environment-friendly refrigerant; the plate / plate fin heat exchanger with the functions of recuperator, evaporator and gas-liquid separator has good heat transfer effect, compact and beautiful structure, modular refrigeration components, convenient disassembly and repair, and strong replaceability.
3) R22 refrigerant and shell and tube heat exchanger are used for more than 80 cubic meters; the three-stage separation mode of "direct collision separation + low-speed centrifugal separation + stainless steel wire mesh demisting separation" is adopted for the gas-liquid separator to separate 99.9% liquid water from the cooled compressed air to prevent the secondary evaporation of water and ensure the low dew point quality of finished gas;
4) Danfoss of Denmark, Fusheng of Taiwan, Panasonic of Japan, Bitzer of Germany, Copeland of Germany, high of Shanghai and other companies are used as refrigeration compressors, which have stable operation, low noise, high cop, reliable performance and long service life;
5) Advanced Danfoss, Emerson and Sporlan are used as refrigeration control elements;
6) Real time display of operation parameters Packaging & Shipping We have three packaging methods:
1. Carton + wooden bottom support
2. Ordinary wooden box + bottom bracket
3. Fumigated wooden box packaging
If other requirements, other packaging can be in accordance with customer requirements
Company Information Shanli purify is a CE and ISO:9001 leading air dryer manufacturer with more than 24 years experience in China. Our products include: >Refrigerated air dryers >Desiccant air dryers >Water Chiller >Pre-cooler >Air filters
Advantages Refrigerant Compressed Air Dryer Advantage: 1.Rapid and Accurate Service-solving Capabilities
2.Sales Marketing: Accurate, timely solution to pre-sale communication problems (pre-sales)
3.Logistics Department Production Department Quality Department: Timely production and delivery in accordance with the quality system standards (sale)
4.After-sales service department: a strong after-sales service network, professional service engineers covering
domestic and global, (after sales)
5.Clients
Major customers: Fu Sheng, Atlas, Ingersoll Rand, Boge, CompAir, SCR and other international
famous brand.
